AWD Dyno
Specification
| DYNO: | AWD1200* | AWD1800 | ||
| Maximum Rated Power/axle @ 240Kph: | 850kW (1134Hp) |
850kW(1134Hp)F |
||
| Maximum Rated Power (combined) @ 240Kph: | 1700kW (2280Hp) | 2550kW (3420Hp) | ||
| Rated Torque (per bed): | 1700Nm (1254Ftlb) | 1700Nm (1254Ftlb) F 3400Nm (2508Ftlb) R |
||
| Rated Torque (combined): | 3400Nm (2508Ftlb) | 5100Nm (3762Ftlb) | ||
| Maximum Weight: | 4.4 Tonne | |||
| Maximum Test Speed: | 250Kph | |||
| Roller Diameter: | 217mm | |||
| Knurled Drive Rollers: | Standard | |||
| Dynamic Roller Balance: | Standard | |||
| Track Minimum: | 600mm (400mm Option) | |||
| Track Maximum: | 2200mm (2400mm Option) | |||
| Wide Track Roller Options: | 400-2200mm/600 – 2400mm | |||
| Wheel Base Minimum: | 2300mm | |||
| Wheel Base Maximum: | 3250mm | |||
| Wheel Base Adjustment: | Automatic or Manual Operation Vehicle database menu |
|||
| Installation: | In Ground or Above Ground | |||
| Speed Sensor: | Digital Pulse | |||
| Force Sensor: | Bi-directional S Beam Load Cell | |||
| Vehicle Tie Down Points: | 26 | |||
| Electrical Requirement: | 3 Phase, 32 AMP, 5 Pin Clipsal 56C532 | |||
| Dynamometer Control Module: | 2WD - 4WD - AWD Control System | |||
| Printer: | Colour Inkjet | |||
| Monitor Display: | 22” LCD - Twin 22” LCD’s Optional | |||
| Hand Control Unit: | Mini Wireless Trackball Keyboard | |||
| Computer Operating System: | Microsoft Windows 7 | |||
| Dynamometer Operating System: | Mainline/DynoLog AWD Software Control System | |||
|
Deluxe Workshop Cabinet with Wheels, Boom & Crash Bars, & Computer/Printer storage: |
Standard | |||
* The AWD1200 can be supplied as a “Twin Retarder Ready” Dyno, initially with only one retarder in the rear bed and with an empty retarder bay for later installation of the second retarder. When the additional retarder is installed in the rear bed, it becomes the AWD1800 model.
The AWD1200, AWD1200TRR and AWD1800 are our most popular models. We can also build larger and more powerful custom All Wheel Drive dynos with a choice of roller sizes and retarder sizes to suit most applications.
NOTE: Specifications subject to change without notice.
